Frame
XS Alpha Silver Aluminium, curved top tube, internal derailleur and dropper post routing, rack and kickstand mount, 135x5 mm ThruSkew
-
Frame
ML , M , L , S , XL , XXL Alpha Silver Aluminium, internal derailleur and dropper post routing, rack and kickstand mount, 135x5 mm ThruSkew
-
Fork
XS , S RockShox Judy, coil spring, preload, TurnKey lockout, 42 mm offset for 27.5" wheel, 100 mm QR, 100 mm travel
-
Fork
ML , M , L , XL , XXL RockShox Judy, coil spring, preload, TurnKey lockout, 46 mm offset for 29" wheel, 100 mm QR, 100 mm travel
-
Front Hub
ML , M , XS , L , S , XL , XXL Formula DC-20, alloy, 6-bolt, 100 mm
-
Rear Hub
ML , M , XS , L , S , XL , XXL Formula DC-22, alloy, 6-bolt, Shimano 8/9/10 freehub, 135x5 mm QR
-
Rear Skewer
173x5 mm QR
-
Rim
ML , M , XS , L , S , XL , XXL Bontrager Kovee, double-wall, Tubeless-Ready, 28-hole, 23 mm width, Presta valve
-
Rim
ML , M , L , XL , XXL Bontrager Kovee, double-wall, Tubeless-Ready, 32-hole, 23 mm width, Presta valve
-
Tire
XS , S Maxxis IKON, tubeless ready, EXO casing, folding bead, 60 tpi, 27.5x2.35''
-
Tire
ML , M , L , XL , XXL Maxxis Rekon Race, tubeless ready, EXO casing, folding bead, 60 tpi, 29x2.35"
-
Rim Strip
ML , M , XS , L , S , XL , XXL Bontrager TLR
-
Shifter
ML , M , XS , L , S , XL , XXL Shimano U6000, 10-speed
-
Rear Derailleur
ML , M , XS , L , S , XL , XXL Shimano CUES U6000 GS
-
Crank
ML , M , XS , S Shimano U4000, 30T chainring, 170 mm length
-
Crank
L , XL , XXL Shimano U4000, 30T chainring, 175 mm length
-
Bottom Bracket
ML , M , XS , L , S , XL , XXL Shimano, 73 mm, threaded cartridge, 122.5 mm spindle
-
Cassette
ML , M , XS , L , S , XL , XXL Shimano CUES LG300, LINKGLIDE, 11-48, 10-speed
-
Chain
ML , M , XS , L , S , XL , XXL Shimano LG500
-
Pedal
ML , M , XS , L , S , XL , XXL VP-536 nylon platform
-
Saddle
ML , M , XS , L , S , XL , XXL Bontrager Verse Short, stainless steel rails
-
Seatpost
XS , S TranzX JD-YSI34, 100 mm travel, internal routing, 34.9 mm, 350 mm length
-
Seatpost
M TranzX JD-YSI34, 125 mm travel, internal routing, 34.9 mm, 405 mm length
-
Seatpost
ML , L , XL TranzX JD-YSI34, 150 mm travel, internal routing, 34.9 mm, 456 mm length
-
Seatpost
XXL TranzX JD-YSI34, 170 mm travel, internal routing, 34.9 mm, 500 mm length
-
Handlebar
XS Bontrager alloy, 31.8 mm, 5 mm rise, 690 mm width
-
Handlebar
S Bontrager alloy, 31.8 mm, 15 mm rise, 720 mm width
-
Handlebar
ML , M , L , XL , XXL Bontrager alloy, 31.8 mm, 15 mm rise, 750 mm width
-
Grips
ML , M , XS , L , S , XL , XXL Trek Line Comp, nylon lock-on
-
Stem
XS , S Bontrager Comp, 31.8 mm, 35 mm length
-
Stem
ML , M , L Bontrager Comp, 31.8 mm, Blendr compatible, 7-degree, 50 mm length
-
Stem
XL Bontrager Comp, 31.8 mm, Blendr compatible, 7-degree, 60 mm length
-
Stem
XXL Bontrager Comp, 31.8 mm, Blendr compatible, 7-degree, 70 mm length
-
Headset
ML , M , XS , L , S , XL , XXL Semi-integrated, 1-1/8"
-
Brake
ML , M , L , XL , XXL Shimano MT200 hydraulic disc
-
Brake Rotor
ML , M , XS , L , S , XL , XXL Shimano RT26, 6-bolt, 160 mm
-
Brake Rotor
ML , M , L , XL , XXL Shimano RT26, 6-bolt, 180 mm
-
Brake Set
ML , M , XS , L , S , XL , XXL Shimano MT200 hydraulic disc
-
Weight
M - 15.00 kg / 33.07 lbs
-
Weight limit
This bike has a maximum total weight limit (combined weight of bicycle, rider and cargo) of 136 kg (300 lb).
